Description
When managing extensive wiring systems, the “sticky mess” left by traditional tapes can be a major technical hurdle. Our Non adhesive PVC tape is the professional’s choice for creating clean, flexible, and adjustable wire harnesses. By removing the adhesive layer, we’ve created a tape that relies on its superior elastic memory to wrap tightly around cables, ensuring a firm hold that won’t degrade, “ooze,” or attract dust over time.
This black PVC non adhesive tape is manufactured using premium-grade Polyvinyl Chloride, optimized for the diverse environmental conditions of the PVC non-adhesive tape India market. It is highly resistant to moisture, oils, and common acids, making it an essential component for automotive engine bays, irrigation systems, and complex electrical distribution boards. Its smooth texture allows for easy sliding of bundled wires through conduits and tight spaces.
Why Engineers Prefer Our Non-Adhesive PVC Solutions:
-
100% Residue-Free: No glue means no sticky buildup on wires, tools, or hands, facilitating easier maintenance and repairs later.
-
Extended 20-Meter Length: The 20-meter roll offers double the length of standard rolls, reducing the need for frequent roll changes during large-scale industrial projects.
-
High Dielectric Strength: Provides excellent secondary insulation and mechanical protection for primary insulated wires.
-
Flexible & Conformable: High elongation properties allow the tape to wrap smoothly around T-joints, bends, and irregular bundles.
Technical Specifications Chart
| Feature | Technical Data |
| Material | Industrial Grade PVC (Non-Sticky) |
| Width | 19 mm (3/4 Inch) |
| Length | 20 Meters (Extra Value Roll) |
| Thickness | 0.125 mm |
| Color | Signal Black |
| Elongation at Break | ≥ 180% |
| Temperature Resistance | -10°C to +80°C |
| Standard | High-Tension Manual Application |
Comparison: Non-Adhesive PVC vs. Standard Electrical Tape
| Feature | Our 20M Non-Adhesive Tape | Standard Adhesive Tape |
| Cleanliness | Stays dry; no glue “bleeding” | Becomes gummy and attracts dirt |
| Re-Usability | Can be unwound and reused | One-time use (Adhesive fails) |
| Heat Stability | Maintains grip through tension | Adhesive can melt and slide |
| Cost Efficiency | 20M Roll = More coverage/less waste | Usually 5M – 8M rolls |
| Application | Wire Looms & Cable Bundling | Permanent Point Insulation |
| Maintenance | Easy to remove for inspections | Requires solvent to clean residue |
